PMT-24V75W2BA Delta switching power supply

Description

PMT-24V75W2BA original full series Delta tablet power supply switching power supply
Output Voltage：24V
Output Power：76.8W
Output Current：3.2A
Input Voltage Range：90-264Vac
Dimensions (L x W x H)：
99 x 97 x 30 mm
3.90” x 3.82” x 1.18”
Unit Weight：0.216 kg (0.48 lb)

Highlights & Features
Household appliance approvals to IEC/EN 60335-1, IEC/EN 61558-1 and IEC/EN 61558-2-16
Universal AC input voltage range
No load power consumption < 0.3W Low profile design : 30mm height OVC III, Pollution Degree 3 Wide operating temp -30°C ~ 70°C (Support -40°C cold start) Conforms to harmonic current IEC/EN 61000-3-2, Class A High MTBF > 700,000 hrs per Telcordia SR-332
Compliance with SEMI-F47
Optional Models
